Basic Info.
Product Description
Product description
Linear shaft features
Items | Linear shaft | Flexible shaft | Hollow shaft |
Material | CK45, SUJ2 | CK45 | SUJ2 |
Heat treatment | Induction hardened | Not hardened | Induction hardened |
Surface hardness | HRC58±2 | HRC15±3 | HRC60±2 |
Surface treated | Hard chrome plated | Hard chrome plated | Hard chrome plated |
Precision | h7, g6, h6 | h7, g6 | h7, g6, h6 |
Roundness | Max3.0µm | Max3.0µm | Max3.0µm |
Straightness | Max5.0µm | Max5.0µm | Max5.0µm |
Chrome thickness | 20-30µm | 30µm | 30µm |
Roughness | Max1.5µm | Max1.5µm | Max1.5µm |
Process machinized | Threading, reduced shaft dia,coaxial holes drilled and tapped, flats-single or multiple, key way, snap ring grooves, radial holes drilled and tapped, chamfering | ||
Linear shaft description
YYZW offers linear shafting in a variety of different options to meet a wide range of customer needs. Available in hardened steel, CK45 material steel, SUJ2 material steel, hollow steel , inch and metric, Simplicity Shafting maintains the ideal surface finish for linear plain bearings and ball bearings.
· Solid round shafting is available in inch sizes from 3/16" thru 4" and metric sizes from 3 mm thru 80 mm
· Machining available upon request
High Reliability
YYZW linear shaft has very straight quality control standards covering every production process. With proper lubrication and use, trouble-free operation for an extended period of time is possible.
Smooth Operation
The high efficiency of linear shaft is vastly superior to conventional shaft. The torque required is less than 30%. Linear motion can be easily changed from rotary motion.
High Durability
Rigidly selected materials, intensive heat treating and processing techniques, backed by years of experience,have resulted in the most durable linear shaft manufactured.
Induction linear shaft, Flexible linear shaft,
linear bearings shaft, hollow linear shaft,
hardened linear shaft, chromed linear shaft
Application
For delicate application in industrial application, machine tool and automation application.
Linear Shafts - Technical Properties.
 | Test linear shaft surface roughness the max roughness is Ra0.4um |
Straight the linear shaft straightness: We control the traighness 0.05mm of linear shaft 300mm |  |
 | Test hardness: S45C materail induction linear shaft, the hardness is HRC55-58 GCr15 (SUJ2) materail induction linear shaft, the hardness is HRC58-63 If flexible shaft, the hardness is based on the shaft material itself |
| Test the linear shaft dia precision, as usually, h7 is the normal tolerance in our stock, But we can offer g6, h6 precision too. if any special tolerance, we are able to customize them for you. |  |
We can machinize all kinds of machining,
Related products
There are many kinds of hardwareproducts we can offer, If you are interested in them, please click the picture and see the details.Production Flow
Packaging and shipping
PP bag for each linear shaft, Standard exported carton outside for small order shipping by international express, such as DHL, TNT, UPS
Wooden box outside for big quantity or very long linear shaft by sea, by air
